Use of cable

as connecting cable for the internal and external wiring of filling-station pumps, petrol station systems, data collection systems and in such areas where an increased oil- and petrol resistance is demanded or regulated by law. Also suitable for laying directly in the ground.

Special features

  • free from lacquer damaging substances and silicone (during production)

Remarks

  • conform to RoHS
  • conform to 2014/35/EU-Guideline ("Low-Voltage Directive") CE
  • We are pleased to produce special versions, other dimensions, core and jacket colours on request.
Conductor material: Bare copper conductor
Conductor class: Acc. to DIN VDE 0295 class 1 resp. IEC 60228 cl. 1
Core insulation: PE
Core identification: BK, WH
Stranding: Cores BK and WH twisted to pairs
Overall stranding: Pairs stranded in layers
Shield3: Plastic clad aluminium foil with subjacent tinned drain wire
Outer sheath: PVC, oil and petrol resistant
Sheath colour: Blue
Rated voltage: Max. 300 V
Testing voltage: C/C 2,0 kV, C/S 1,0 kV
Conductor resistance: Max 36,7 Ω / km
Insulation resistance: Min. 5.000 MΩ x km
Min. bending radius fixed: 10 x d during installation
Operat. temp. fixed min/max: -30 °C / +70 °C
Operat. temp. moved min/max: -5 °C / +70 °C

Table of items

Product No.
Dimension
[n x mm²]
Outer-Ø
[mm]
Cu-Index
[kg/km]
Weight
[kg/1.000]
Sheath colour
Variant
2002238 1 X 2 X 0,8 7,0 14,4 67,0 blue V0: RE-2Y(ST)YÖ
2002239 2 X 2 X 0,8 9,2 26,0 130,0 blue V0: RE-2Y(ST)YÖ
