Use of cable

as connecting cable for the internal and external wiring of filling-station pumps, petrol station systems, data collection systems and in such areas where an increased oil- and petrol resistance is demanded or regulated by law. Also suitable for laying directly in the ground.

Special features

  • free from lacquer damaging substances and silicone (during production)

Remarks

  • conform to RoHS
  • conform to 2014/35/EU-Guideline ("Low-Voltage Directive") CE
  • We are pleased to produce special versions, other dimensions, core and jacket colours on request.
Conductor material: Bare copper conductor
Conductor class: Acc. to DIN VDE 0295 class 1 resp. IEC 60228 cl. 1
Core insulation: PVC
Core identification: Acc. to DIN VDE 0293-308 up to 5 cores coloured, from 6 cores black with white numerals with or without GNYE
Overall stranding: Cores stranded in layers
Inner sheath material: Filler sheath
Outer sheath: PVC, oil and petrol resistant
Sheath colour: Black or blue
Rated voltage: Uo/U: 0,6/1 kV
Testing voltage: 4 kV
Insulation resistance: 20 MΩ x km
Current-carrying-capacity: Acc. to DIN VDE, see Technical Guidelines
Min. bending radius fixed: 15 x d
Operat. temp. fixed min/max: -30 °C / +70 °C
Operat. temp. moved min/max: -5 °C / +50 °C
Standard: Similar to DIN VDE 0250

Table of items

Product No.
Dimension
[n x mm²]
Outer-Ø
[mm]
Cu-Index
[kg/km]
Weight
[kg/1.000]
Sheath colour
Variant
4000216 3 G 1,5 10,6 43,0 235,0 black V1: (N)YYÖ-J schwarz / black
4000225 5 G 1,5 12,3 72,0 309,0 black V1: (N)YYÖ-J schwarz / black
4000229 7 G 1,5 13,3 101,0 354,0 black V1: (N)YYÖ-J schwarz / black
4000556 2 X 1,5 10,1 29,0 213,0 blue V2: (N)YYÖ-O blau / blue
4000217 3 G 1,5 10,6 43,0 235,0 blue V2: (N)YYÖ - blau / blue
