Use of cable

as connecting cable for the internal and external wiring of filling-station pumps, petrol station systems, data collection systems and in such areas where an increased oil- and petrol resistance is demanded or regulated by law. Also suitable for laying directly in the ground.

Special features

  • free from lacquer damaging substances and silicone (during production)

Remarks

  • conform to RoHS
  • conform to 2014/35/EU-Guideline ("Low-Voltage Directive") CE
  • We are pleased to produce special versions, other dimensions, core and jacket colours on request.
Conductor material: Bare copper strand
Conductor class: Acc. to DIN VDE 0295 class 5 resp. IEC 60228 cl. 5
Core insulation: LIY(ST)YÖ: PVC; LI2Y(ST)YÖ: PE
Core identification: Special colours
Overall stranding: Cores stranded in layers
Shield3: Plastic clad aluminium foil with subjacent tinned drain wire
Outer sheath: PVC, oil and petrol resistant
Sheath colour: Blue
Rated voltage: LIY(ST)YÖ: 500 V; LI2Y(ST)YÖ: 900 V
Testing voltage: LIY(ST)YÖ: 1,2 kV; LI2Y(ST)YÖ: 2,5 kV
Conductor resistance: Max. 26,0 Ω / km
Min. bending radius fixed: 10 x d during installation
Min. bending radius moved: 15 x d
Operat. temp. fixed min/max: -30 °C / +70 °C
Operat. temp. moved min/max: - 5 °C / +70 °C

Table of items

Product No.
Dimension
[n x mm²]
Outer-Ø
[mm]
Cu-Index
[kg/km]
Weight
[kg/1.000]
Sheath colour
Variant
2002235 3 X 0,75 6,0 29,0 77,0 blue V1: LIY(ST)YÖ-OB
2002236 4 X 0,75 8,2 36,0 70,0 blue V2: LI2Y(ST)YÖ-OB
